Data Flow Task

Data Flow Task

Data Flow Task

Data Flow Task

Sequence

Sequence Container

Sequence

Sequence Container

Task

Execute SQL Task

Task

Execute SQL Task

Task

Execute SQL Task

Task

Execute SQL Task

Y

Configuration setting in SSIS_Configurations that determines if Alerts will be send via e-mail in case of an abend or data problems.

/* SQL Delete from DimCurriculum fromTemp Table */ select count(*) as RWC FROM [EnterpriseDW].[dbo].[FactActiveEnrollmentSnapshot] as Fact INNER JOIN [EnterpriseDW].[dbo].DimCurriculum Dim on ( Dim.CurriculumSK = Fact.CurriculumSK ) WHERE Dim.ReferenceNumberAK in ( SELECT ReferenceNumberAK FROM [dbo].[Update_dbo_DimCurriculum] )

" /* SQL Delete from DimCurriculum fromTemp Table */ select count(*) as RWC FROM " + (@[User::EDWLinkedServerName] == "N/A" ? "" : "[" + @[User::EDWLinkedServerName]+"]." ) + "["+ @[User::EDWDBName] + "].[dbo].[FactActiveEnrollmentSnapshot] as Fact INNER JOIN " + (@[User::EDWLinkedServerName] == "N/A" ? "" : "[" + @[User::EDWLinkedServerName]+"]." ) + "["+ @[User::EDWDBName] + "].[dbo].DimCurriculum Dim on ( Dim.CurriculumSK = Fact.CurriculumSK ) WHERE Dim.ReferenceNumberAK in ( SELECT ReferenceNumberAK FROM [dbo].[Update_dbo_DimCurriculum] ) "

Stores the number of Fact rows that are using the row in a dimension. Will be used to determine if records removed from the Source System can be deleted.

DELETE FROM [EnterpriseDW] .[dbo].[DimCurriculum] WHERE CurriculumSK IN ( SELECT CurriculumSK FROM [dbo].[Obsolete_DimCurriculum] obs WHERE obs.DoNotDeleteFlag = 0 )

" DELETE FROM " + (@[User::EDWLinkedServerName] == "N/A" ? "" : "[" + @[User::EDWLinkedServerName]+"]." ) + "["+ @[User::EDWDBName] + "] .[dbo].[DimCurriculum] WHERE CurriculumSK IN ( SELECT CurriculumSK FROM [dbo].[Obsolete_DimCurriculum] obs WHERE obs.DoNotDeleteFlag = 0 ) "

This contains the Delete Statement to delete rows from the dimension that have been deleted in the Source System.

Configuration setting from SSIS_Configuration to specify the domain where the e-mail server is running.

EnterpriseDW

Configuration setting in SSIS_Configurations that specifies the name of the Enterprise Data Warehouse.

N/A

If the Enterprise Data Warehouse resides on a different server from the DWStaging and DWoperations databases, a linked server must be defined and the name populated into the Var_EDWLinkedServername. If it resides on the same server, this setting must be set to ?N/A?. This is a configuration setting from SSIS_Configurations.

The list of files to be attached to the e-mail detailing record counts and data validation issues.

Testing (text maintained in SSIS Configurations table)

The text that will be coded in the body of the e-mail. This is an configuration setting in SSIS_Configurations that will be appended to the end of the e-mail.

C:\DW Local Stuff\SSIS\

The directory on the File System where the files to be attached to the e-mail for notifications will be stored. This is a configuration setting from SSIS_Configurations.

help@hetgroup.org

Configuration setting from SSIS_Configurations that will specify the From E-mail address to be used in e-mail notifications.

datawarehouse

The configuration setting from SSIS_Configurations that specify the password used for the e-mail server when sending e-mail notifications.

ipeterso@hetgroup.org

The configuration setting from SSIS_Configurations that specify the To Email address when sending e-mail notifications. This cannot be multiple e-mail addresses, but can be a distribution list.

windows

The configuration setting from SSIS_Configurations that specify the userid used for the e-mail server when sending e-mail notifications.

exec usp_DimCurriculum_Select

" exec usp_DimCurriculum_Select '" + @[User::IncrementalBeginDtTm] + "' , '" + @[User::IncrementalEndDtTm] + "'"

This contains a string that will execute the stored procedure to retrieve all the changes to the Curriculum data in the source system.

Jan 1 1900 12:00AM

The IncrementalBeginDtTm setting will contain the start date and time for which updates will be extracted. This is a configuration setting from SSIS_Configurations that are set in the Control Package.

Mar 4 2016 10:33AM

The IncrementalEndDtTm setting will contain the End Date and Time for which updates will be extracted. These values will be compared against the RowUpdatedOn column on the tables in the DWStaging database to determine which rows to extract and load into the Enterprise Data Warehouse.

/* SQL Insert into DimCurriculum from New Temp Table */ INSERT INTO [EnterpriseDW].[dbo].[DimCurriculum] ( ReferenceNumberAK ,ReferenceNumber ,Term ,TermTitle ,CourseId ,CurrentTerm ,CurrentCourseId ,CourseIdPrefix ,ClassTitle ,CourseTypeCode ,CourseType ,CreditNonCreditVocational ,CreditTypeCode ,CreditType ,CreditNonCredit ,ICSCode ,InstructionalClassification ,DivisionCode ,Division ,DepartmentCode ,Department ,CampusCode ,Campus ,CenterCode ,Center ,MinimumClassSize ,MaximumClassSize ,ClassStatusCode ,ClassStatus ,TimeBlockCode ,TimeBlock ,DeliveryMethod ,PrimaryInstructorId ,PrimaryInstructorFullName ,PrimaryInstructorLastName ,PrimaryInstructorFirstName ,PrimaryInstructorMiddleInitial ,SessionCode ,Session ,Honors ,WeekendCollege ,DualEnrollment ,IndependentStudy ,Apprenticeship ,VirtualCollege ,Online100Percent ,WebEnabled ,WebBlended ,ScheduleInformation ,PrimaryInstructorType ,ICSCategoryCode ,InstructionalClassificationCategory ,TermCourseIdCount ,IsTermCourseIdCountGE10 ,IsCourseRepeatable ,CourseNumberTimesForCredit ,RowIsCurrent ,RowStartDate ,RowEndDate ,CourseLevel ,CreditNonCreditVocationalTest ,DivisionDescription, DepartmentDescription ) SELECT ReferenceNumberAK ,ReferenceNumber ,Term ,TermTitle ,CourseId ,CurrentTerm ,CurrentCourseId ,CourseIdPrefix ,ClassTitle ,CourseTypeCode ,CourseType ,CreditNonCreditVocational ,CreditTypeCode ,CreditType ,CreditNonCredit ,ICSCode ,InstructionalClassification ,DivisionCode ,Division ,DepartmentCode ,Department ,CampusCode ,Campus ,CenterCode ,Center ,MinimumClassSize ,MaximumClassSize ,ClassStatusCode ,ClassStatus ,TimeBlockCode ,TimeBlock ,DeliveryMethod ,PrimaryInstructorId ,PrimaryInstructorFullName ,PrimaryInstructorLastName ,PrimaryInstructorFirstName ,PrimaryInstructorMiddleInitial ,SessionCode ,Session ,Honors ,WeekendCollege ,DualEnrollment ,IndependentStudy ,Apprenticeship ,VirtualCollege ,Online100Percent ,WebEnabled ,WebBlended ,ScheduleInformation ,PrimaryInstructorType ,ICSCategoryCode ,InstructionalClassificationCategory ,TermCourseIdCount ,IsTermCourseIdCountGE10 ,IsCourseRepeatable ,CourseNumberTimesForCredit ,RowIsCurrent ,RowStartDate ,RowEndDate ,CourseLevel ,CreditNonCreditVocationalTest, DivisionDescription, DepartmentDescription FROM [dbo].[Staged_dbo_DimCurriculum__New]

" /* SQL Insert into DimCurriculum from New Temp Table */ INSERT INTO " + (@[User::EDWLinkedServerName] == "N/A" ? "" : "[" + @[User::EDWLinkedServerName]+"]." ) + "["+ @[User::EDWDBName] + "].[dbo].[DimCurriculum] ( ReferenceNumberAK ,ReferenceNumber ,Term ,TermTitle ,CourseId ,CurrentTerm ,CurrentCourseId ,CourseIdPrefix ,ClassTitle ,CourseTypeCode ,CourseType ,CreditNonCreditVocational ,CreditTypeCode ,CreditType ,CreditNonCredit ,ICSCode ,InstructionalClassification ,DivisionCode ,Division ,DepartmentCode ,Department ,CampusCode ,Campus ,CenterCode ,Center ,MinimumClassSize ,MaximumClassSize ,ClassStatusCode ,ClassStatus ,TimeBlockCode ,TimeBlock

This is the SQL statement to insert the new records into DimCurriculum.

100

The number of rows that were loaded into the Dimension. This is will be compared against the row count from the source system.

/* SQL Update DimCurriculum from temp table */ UPDATE [EnterpriseDW].[dbo].[DimCurriculum] SET ReferenceNumberAK = SCD1.ReferenceNumberAK ,ReferenceNumber = SCD1.ReferenceNumber ,Term = SCD1.Term ,TermTitle = SCD1.TermTitle ,CourseId = SCD1.CourseId ,CurrentTerm = SCD1.CurrentTerm ,CurrentCourseId = SCD1.CurrentCourseId ,CourseIdPrefix = SCD1.CourseIdPrefix ,ClassTitle = SCD1.ClassTitle ,CourseTypeCode = SCD1.CourseTypeCode ,CourseType = SCD1.CourseType ,CreditNonCreditVocational = SCD1.CreditNonCreditVocational ,CreditTypeCode = SCD1.CreditTypeCode ,CreditType = SCD1.CreditType ,CreditNonCredit = SCD1.CreditNonCredit ,ICSCode = SCD1.ICSCode ,InstructionalClassification = SCD1.InstructionalClassification ,DivisionCode = SCD1.DivisionCode ,Division = SCD1.Division ,DepartmentCode = SCD1.DepartmentCode ,Department = SCD1.Department ,CampusCode = SCD1.CampusCode ,Campus = SCD1.Campus ,CenterCode = SCD1.CenterCode ,Center = SCD1.Center ,MinimumClassSize = SCD1.MinimumClassSize ,MaximumClassSize = SCD1.MaximumClassSize ,ClassStatusCode = SCD1.ClassStatusCode ,ClassStatus = SCD1.ClassStatus ,TimeBlockCode = SCD1.TimeBlockCode ,TimeBlock = SCD1.TimeBlock ,DeliveryMethod = SCD1.DeliveryMethod ,PrimaryInstructorId = SCD1.PrimaryInstructorId ,PrimaryInstructorFullName = SCD1.PrimaryInstructorFullName ,PrimaryInstructorLastName = SCD1.PrimaryInstructorLastName ,PrimaryInstructorFirstName = SCD1.PrimaryInstructorFirstName ,PrimaryInstructorMiddleInitial = SCD1.PrimaryInstructorMiddleInitial ,SessionCode = SCD1.SessionCode ,[Session] = SCD1.[Session] ,Honors = SCD1.Honors ,WeekendCollege = SCD1.WeekendCollege ,DualEnrollment = SCD1.DualEnrollment ,IndependentStudy = SCD1.IndependentStudy ,Apprenticeship = SCD1.Apprenticeship ,VirtualCollege = SCD1.VirtualCollege ,Online100Percent = SCD1.Online100Percent ,WebEnabled = SCD1.WebEnabled ,WebBlended = SCD1.WebBlended ,ScheduleInformation = SCD1.ScheduleInformation ,PrimaryInstructorType = SCD1.PrimaryInstructorType ,ICSCategoryCode = SCD1.ICSCategoryCode ,InstructionalClassificationCategory = SCD1.InstructionalClassificationCategory ,TermCourseIdCount = SCD1.TermCourseIdCount ,IsTermCourseIdCountGE10 = SCD1.IsTermCourseIdCountGE10 ,IsCourseRepeatable = SCD1.IsCourseRepeatable ,CourseNumberTimesForCredit = SCD1.CourseNumberTimesForCredit ,CourseLevel = SCD1.CourseLevel ,CreditNonCreditVocationalTest = SCD1.CreditNonCreditVocationalTest,DivisionDescription = SCD1.DivisionDescription ,DepartmentDescription = SCD1.DepartmentDescription FROM [EnterpriseDW].[dbo].[DimCurriculum] AS [DIM] INNER JOIN [dbo].[Staged_dbo_DimCurriculum__Type1Update] AS SCD1 ON Dim.ReferenceNumberAK = SCD1.ReferenceNumberAK

" /* SQL Update DimCurriculum from temp table */ UPDATE " + (@[User::EDWLinkedServerName] == "N/A" ? "" : "[" + @[User::EDWLinkedServerName]+"]." ) + "["+ @[User::EDWDBName] + "].[dbo].[DimCurriculum] SET ReferenceNumberAK = SCD1.ReferenceNumberAK ,ReferenceNumber = SCD1.ReferenceNumber ,Term = SCD1.Term ,TermTitle = SCD1.TermTitle ,CourseId = SCD1.CourseId ,CurrentTerm = SCD1.CurrentTerm ,CurrentCourseId = SCD1.CurrentCourseId ,CourseIdPrefix = SCD1.CourseIdPrefix ,ClassTitle = SCD1.ClassTitle ,CourseTypeCode = SCD1.CourseTypeCode ,CourseType = SCD1.CourseType ,CreditNonCreditVocational = SCD1.CreditNonCreditVocational ,CreditTypeCode = SCD1.CreditTypeCode ,CreditType = SCD1.CreditType ,CreditNonCredit = SCD1.CreditNonCredit ,ICSCode = SCD1.ICSCode ,InstructionalClassification = SCD1.InstructionalClassification

This is the SQL update statement for DimCurriculum

c:\stubfile.txt

Temporary file name that will be used to create the e-mail notifications. This is a configuration setting from SSIS_Configurations.

25

The SMTPPort for the e-mail server to be used when sending notification e-mails. This is a configuration setting from SSIS_Configurations.

www.ad.hetgroup.org

The SMTP Server Name contains the name for the e-mail server. This is a configuration setting from SSIS_Configurations.

101

This is the Row count from the Source System to compare against that of the DimCurriculum table to ensure that all records were copied.
